Render Note

Article Image

Render Note is used in Scripting. It works by displaying the HTML of a Code note, via an attribute.

Creating a render note#

  1. Create a Code note with the HTML language, with what needs to be displayed (for example <p>Hello world.</p>).
  2. Create a Render Note.
  3. Assign the renderNote relation to point at the previously created code note.

Dynamic content#

A static HTML is generally not enough for Scripting. The next step is to automatically change parts of the note using JavaScript.

For a simple example, we are going to create a render note that displays the current date in a field.

To do so, first create an HTML code note with the following content:

&lt;h1&gt;Current date &amp; time&lt;/h1&gt;
The current date &amp; time is &lt;span class="date"&gt;&lt;/span&gt;

Now we need to add the script. Create another Code, but this time of JavaScript (frontend) language. Make sure the newly created note is a direct child of the HTML note created previously; with the following content:

const $dateEl = api.$container.find(".date");
$dateEl.text(new Date());

Now create a render note at any place and set its ~renderNote relation to point to the HTML note. When the render note is accessed it will display:

Current date & time
The current date & time is Sun Apr 06 2025 15:26:29 GMT+0300 (Eastern European Summer Time)

Examples#
